CISCO
Cisco IE-2000-4TS-G-L
Cisco IE-2000-4TS-G-L
Couldn't load pickup availability
IE-2000-4TS-G-L
| Model: | IE-2000-4TS-G-B - Industrial Ethernet 2000 Series |
| Detail: |
IE 4 10/100,2 SFP Gig port, Base
|
Details
IE-2000-4TS-G-B is the IE2000 series IE 4 10/100, 2 GE, and LAN Base switch. The Cisco IE 2000 Series are designed for low cost, low ports, and small sizes. They offer:
1. Four, eight, or 16 10/100Base-T Ethernet ports (Small Form-Factor Pluggable [SFP] downlinks on selected models); fixed configurations with a compact form factor
2. Two gigabit combo ports: SFP (100 Mbps and 1 Gbps) or RJ45 uplink
3. Dual-input DC power supply, alarm relays, DIN rail mount
4. Industrial Power over Ethernet (PoE) solution
5. Conformal coating available
6. Swappable SD flash card and mini-USB connector
7. Industrial environmental compliance and certifications
8. Industrial partner applications: Ethernet/IP and PROFINET
|
Part Number |
IE-2000-4TS-G-B |
|
Total Ports |
6 |
|
RJ45 Ports |
4 FE |
|
SFP Ports |
2 GE |
|
Manufacturing license |
LAN Base |
|
Dimensions (H x W x D) including DIN rail |
5.1” H x 2.95” W x 4.51” D in (130mm H x 74.9mm W x 115mm D) |
|
Weight |
IE-2000 6 ports chassis: 2.45 lb (1.11 kg) |
